Dell Precision T3630 Xeon E3-1230 16GB DDR4 1TB HDD 4GB GPU
Overview
Dell Precision T3630 Server drives SMB and remote office/branch office applications faster and grow your data with a powerful and expandable 1-socket tower server. This model is the Dell Precision T3630 server with Intel® Xeon® E3-1230 processor, Optional Operating System, 16GB Memory, 1TB Hard Drive, SATA
Quick Specs
Table 1 shows the quick spec.
| Product Model | Dell Precision T3630Xeon E3-1230 16GB 1TB SATA Tower Server |
| Product Series | Dell Precision T3630 Server |
| Customizable | Intel® Xeon® E3-1230 , Optional Operating System, 16GB Memory, 1TB Hard Drive, SATA |
| Processor | Intel® Xeon® E3-1230 3.4GHz, 8M cache, 4C/8T, turbo (80W) |
| Operating System | No Operating System. WINDOWS |
| Memory | 16GB (1x16GB) 2400MT/s DDR4 ECC UDIMM |
| Hard Drive | 1TB 7.2K RPM SATA 6Gbps 3.5in Hot-plug Hard Drive |
| RAID Controllers | PERC S130, PERC H330, PERC H730, PERC H830 |
| Dimensions | Height: chassis base height – 430.3 mm/17.04 in With foot – 443.3 mm/17.45 in With wheel – 471.3 mm/18.55 in Width: chassis base width – 218 mm/8.58 in Depth: front to rear wall (w/o bezel) – 542.2 mm/21.33 in |
Product Details
Figure 1 shows the front and back panel description of Dell Precision T3630 Server.
Front Panel (Tower mode):
| ① | Power-on indicator, power button | ⑥ | USB management port/iDRAC Direct port |
| ② | NMI button and System identification button | ⑦ | USB connector |
| ③ | LCD menu buttons | ⑧ | Optical drive or tape drives |
| ④ | LCD panel | ⑨ | Hard drives |
| ⑤ | Information tag |
Note：There is also a rack mode of this server, which provides a Video connector on the front panel.
Back Panel:
| ① | Power supply units (PSU1 and PSU2) | ⑦ | USB connectors (2) |
| ② | PCIe expansion card slots (4) | ⑧ | Ethernet connectors |
| ③ | iDRAC port (optional) | ⑨ | Ethernet connectors |
| ④ | vFlash media card slot (optional) | ⑩ | System identification button |
| ⑤ | Serial connector | ⑪ | Video connector |
| ⑥ | USB connectors (4) |
